Opis izdelka

Maximum number of SMP processors:
– 1
Compatible processor series:
– AMD Ryzen 9 7th Gen
– AMD Ryzen 5
– AMD Ryzen 7
Processor manufacturer:
– AMD
Processor socket:
– Socket AM5
Windows operating systems supported:
– Windows 11 x64
– Windows 10 x64
Motherboard chipset:
– AMD B650
Audio output channels:
– 7.1 channels
Audio chip:
– Realtek ALC897
Motherboard chipset family:
– AMD
Motherboard form factor:
– ATX
Memory channels:
– Dual-channel
Number of memory slots:
– 4
Supported memory types:
– DDR5-SDRAM
Memory slots type:
– DIMM
Maximum internal memory:
– 128 GB
Unbuffered memory:
– Yes
Depth:
– 244 mm
Width:
– 305 mm
Wi-Fi standards:
– 802.11b
– 802.11a
– 802.11g
– Wi-Fi 4 (802.11n)
– Wi-Fi 5 (802.11ac)
– Wi-Fi 6E (802.11ax)
Top Wi-Fi standard:
– Wi-Fi 6E (802.11ax)
Ethernet interface type:
– 2.5 Gigabit Ethernet
Wi-Fi:
– Yes
Ethernet LAN:
– Yes
LAN controller:
– Dragon RTL8125BG
Bluetooth:
– Yes
TPM connector:
– Yes
RGB LED pin header:
– Yes
Number of SATA III connectors:
– 2
Front panel audio connector:
– Yes
Thunderbolt headers:
– 1
USB 2.0 connectors:
– 2
ATX Power connector (24-pin):
– Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors:
– 2
CPU fan connector:
– Yes
BIOS type:
– UEFI AMI
Supported storage drive interfaces:
– M.2, SATA III
Supported storage drive types:
– HDD & SSD
RAID levels:
– 10
– 1
– 0
RAID support:
– Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity:
– 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:
– 4
Headphone outputs:
– 1
HDMI ports quantity:
– 1
Microphone in:
– Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:
– 1
S/PDIF out port:
– Yes
DisplayPort version:
– 1.4
DisplayPorts quantity:
– 1
Ethernet LAN (RJ-45) ports:
– 1
USB 2.0 ports quantity:
– 2
PCI Express x16 (Gen 3.x) slots:
– 1
PCI Express x16 (Gen 5.x) slots:
– 1
