Opis izdelka

Processor manufacturer:
– AMD
Supported processor sockets:
– Socket AM5
Compatible processor series:
– AMD Ryzen 7 7th Gen
– AMD Ryzen 9 7th Gen
Processor socket:
– Socket AM5
Parallel processing technology support:
– Not supported
Motherboard chipset:
– AMD B650
Motherboard form factor:
– ATX
PC health monitoring:
– Fan
Audio chip:
– Realtek ALC897
Motherboard chipset family:
– AMD
Audio output channels:
– 7.1 channels
Windows operating systems supported:
– Windows 11 x64
Supported memory clock speeds:
– 5200
– 5000
– 5600
– 4800
– 6000
– 6200
– 6400
– 5800
– 5400
Maximum internal memory:
– 192 GB
Supported memory clock speed (max):
– 6000 MHz
Number of memory slots:
– 4
Supported memory types:
– DDR5-SDRAM
Width:
– 243.8 mm
Depth:
– 304.8 mm
LAN controller:
– Realtek RTL8125B
Top Wi-Fi standard:
– Wi-Fi 6 (802.11ax)
Wi-Fi standards:
– Wi-Fi 4 (802.11n)
– 802.11a
– Wi-Fi 6 (802.11ax)
– 802.11g
– 802.11b
– Wi-Fi 5 (802.11ac)
Bluetooth:
– Y
Wi-Fi:
– Y
Bluetooth version:
– 5.3
Ethernet LAN:
– Y
Ethernet interface type:
– 2.5 Gigabit Ethernet
USB 3.2 Gen 1 (3.1 Gen 1) connectors:
– 2
ATX Power connector (24-pin):
– Y
CPU fan connector:
– Y
Front panel connector:
– Y
Chassis intrusion connector:
– Y
Front panel audio connector:
– Y
USB 2.0 connectors:
– 4
USB 3.2 Gen 2 (3.1 Gen 2) connectors:
– 1
BIOS type:
– UEFI AMI
RAID levels:
– 0
– 1
– 10
Supported storage drive interfaces:
– M.2, SATA
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:
– 3
HDMI version:
– 2.1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:
– 4
HDMI ports quantity:
– 1
Ethernet LAN (RJ-45) ports:
– 1
USB 3.2 Gen 2×2 Type-C ports quantity:
– 1
Headphone outputs:
– 1
Line-in:
– Y
Microphone in:
– Y
Number of M.2 (M) slots:
– 2
PCI Express x16 (Gen 3.x) slots:
– 1
